MODEL |
SX42585W385C |
|
|
|
Left Hand Drive |
|
|
Driving type |
6×6 |
|
|
Curb weight |
8800kg |
|
|
G.C.W |
< 90000kg（technology） |
|
|
Overall Dimension |
6850×2490×3700mm |
|
|
Wheelbase |
3775+1400mm |
|
|
Max. Speed (Full load) / (empty ) |
50-70 km/h / 90km/h |
|
|
Max. Grade ability |
30 |
|
|
Engine |
Model |
CUMMINS ISM11E5-440. turbocharger, in-line, 6 cylinders, Full-electric controlled. |
|
Emission Standard |
EURO-V |
|
|
Rated output power |
440HP@1900rpm |
|
|
Max.Torque |
2150N.m/1100～1300rpm |
|
|
Displacement |
10.8L |
|
|
Transmission |
model |
FAST 12JSDX220TA-B Manual, 12F/2R, with ZQC2000 transfer case. |
|
Front axle |
Model |
1×MAN 9.5T |
|
Rear axle |
Model |
2×16T MAN double reduction axle，ratio 4.769 |
|
Clutch |
￠430 diaphragm clutch |
|
|
Steering |
ZF technology |
|
|
Frame |
850×300（8+7） |
|
|
Suspension |
multiple leaf springs front and rear/Four main spring + four bolts |
|
|
Fuel tank |
500L Aluminum alloy |
|
|
Wheels and tires |
315/80R22.5, TR918 pattern |
|
|
ABS |
WABCO 6-ways ABS |
|
|
Cabin |
FX3000 warmer cab/one sleeping bed/hydraulic driver seat/ four-point hydraulic suspension cab/ A/C / metal bumper |
|
|
Others |
With mud-guard, oil-bath air filter, JOST 50# Fifth wheel, 180Ah cold area battery, fire extinguisher, cold areas cable. |
|
