| MODEL | SX41855U361 | |
| Driving type | 4×2 | |
| Curb weight | 8800KG | |
| Overall Dimension(LxWxH) | 6350×2490×3800mm（high roof） | |
| Wheelbase | 3600mm | |
| Max. Grade ability | 30% | |
| Engine | Brand | WEICHAI |
| Model | WP12.400E201 | |
| Emission Standard | EURO-Ⅱ | |
| Rated output power | 400HP | |
| Rated speed | 1900rpm | |
| Maximum Torque | 1920N.m/1000～1400r/pm | |
| Displacement | 11.596L | |
| Transmission | Brand | FAST |
| Model | 12JSD200T-B，12F/2R, manual | |
| Front axle | 7500kg，MAN 7.5T | |
| Rear axle | 2×13000kg，2×13T MAN double reduction drive axle. | |
| Clutch | ￠430 diaphragm clutch | |
| Steering | ZF technology | |
| Frame | 850*300*8 | |
| Suspension | multiple leaf springs front and rear | |
| Fuel tank | 400L aluminium alloy | |
| Wheels and tires | 12R22.5 Tubeless tire | |
| Cabin |
|
|
