| MODEL | SX4255HU324 | |
| Driving type | 6×4 | |
| Curb weight | 8800KG | |
| Overall Dimension(LxWxH) | 6850×2490×3700mm（high roof） | |
| Wheelbase | 3175+1400mm | |
| Max. Grade ability | 30% | |
| Engine | Brand | CUMMINS / WEICHAI |
| Model | ISM11-385 / WP12.400E201 | |
| Emission Standard | EURO-IV / EURO-II | |
| Rated output power | 385HP / 400HP | |
| Rated speed | 1900rpm | |
| Maximum Torque | 2150N.m/1920N.M/1000～1300r/pm | |
| Displacement | 10.8L / 11.596L | |
| Transmission | Brand | FAST |
| Model | 12JSD200T-B，12F/2R, Manual | |
| Front axle | MAN 7.5T | |
| Rear axle | 2×13T MAN double reduction drive axle. | |
| Clutch | ￠430 diaphragm clutch | |
| Steering | ZF technology | |
| Frame | 850*300*8 | |
| Suspension | multiple leaf springs front and rear | |
| Fuel tank | 400L aluminium alloy | |
| Wheels and tires | 12.00R20 Radial tire, 10+1 | |
| Cabin | H3000 High-roof Cabin, with auto A/C, With two sleepers, with inter-locking, metal bumper and others. | |
