| MODEL | SX5255GJBDR384 | |
| Left Hand / Right Hand | ||
| Driving type | 6×4 | |
| Curb weight | 15600KG | |
| Overall Dimension(LxWxH) | 9000×2490×3900mm | |
| Wheelbase | 3775+1400mm | |
| Max. Speed | 80 km/h | |
| Max. Grade ability | 30% | |
| Engine/发动机 | Brand | CUMMINS |
| Model | ISME345-30 | |
| Emission Standard | EUROⅡ | |
| Rated output power | 345HP | |
| Rated speed | 1900rpm | |
| Max.Torque | 1710N.m/1000～1200r/pm | |
| Displacement(L) | 10.8L | |
| Transmission | Brand | FAST |
| Model | 10JSD180 , manual , 10F/2R | |
| Front axle | Model | MAN 9.5T |
| Rear axle | Model | 16T MAN double reduce axle， |
| Clutch | ￠430 diaphragm clutch | |
| Steering | ZF technology | |
| Frame | 850×300（8+7） | |
| Suspension | multiple leaf springs front and rear/Four main spring + four bolts | |
| Fuel tank | 300L fuel tank | |
| Wheels and tires | 12.00R20 | |
| Cabin | F3000 D cab/ one sleeping bed/hydraulic driver seat/ four-point hydraulic suspension cab/ A/C / metal bumper | |
| MIXER TANK | Concrete mixing tank volume: 10m3 with BW300 steel material, 4mm thickness. With Italy reduction, motor and pump system. AKB/EATON/PMP brands option. |
|
