MODEL | SX5155TSMJR442 | |
Left Hand / Right Hand | ||
Driving type | 4×2 | |
Curb weight | 10000KG | |
Overall Dimension(LxWxH) | 7700×2490×3300mm | |
Wheelbase | 4375+1400mm | |
Max. Speed | 90 km/h | |
Max. Grade ability | 30% | |
Engine/发动机 | Brand | WEICHAI |
Model | WP10.340E22 | |
Emission Standard | EUROⅡ | |
Rated output power | 340HP | |
Rated speed | 2200rpm | |
Max.Torque | 1240N.m/1400~1600r/pm | |
Displacement(L) | 9.726L | |
Transmission | Brand | FAST |
Model | 9JS150T-B , manual , 9F/1R | |
Front axle | Model | MAN 7.5T |
Rear axle | Model | 13T MAN double reduce axle, |
Clutch | ¢430 diaphragm clutch | |
Steering | ZF technology | |
Frame | 850×300(8+5) | |
Suspension | multiple leaf springs front and rear/Four main spring + four bolts | |
Fuel tank | 400L fuel tank | |
Wheels and tires | 12.00R20 | |
Cabin | F3000 D cab/ one sleeping bed/hydraulic driver seat/ four-point hydraulic suspension cab/ A/C / metal bumper | |
CARGO BOX | Cargo size: 5000*2300*600MM |
