MODEL |
SX5255GYSDN434 |
|
|
|
Left Hand Drive |
|
|
Driving type |
6×4 |
|
|
Curb weight |
12500kg |
|
|
Overall Dimension |
10000×2490×3350mm (technology) |
|
|
Wheelbase |
4300+1400mm |
|
|
Max. Speed |
90 km/h |
|
|
Max. Grade ability |
30 |
|
|
Engine |
Model |
WEICHAI WP10.300E22 |
|
Emission Standard |
EURO-Ⅱ |
|
|
Rated output power |
300HP@2200rpm |
|
|
Max.Torque |
1500N.m@1200r/pm |
|
|
Displacement |
9.726L |
|
|
Transmission |
model |
FAST RTD11509C+QH50PTO, Manual, 9F/1R |
|
Front axle |
Model |
MAN 7.5T |
|
Rear axle |
Model |
2*MAN 13T double reduction axle， ratio 4.8 |
|
Clutch |
￠430 diaphragm clutch |
|
|
Steering |
ZF technology, left hand drive |
|
|
Suspension |
multiple leaf springs front and rear, with rear stable bar |
|
|
Fuel tank |
380L |
|
|
Wheels and tires |
12R22.5 Tubeless tire |
|
|
ABS |
ABS |
|
|
Cabin |
F3000 Flat roof cabin/ one sleeping bed/ air -driver seat/ four-point hydraulic suspension cab/ A/C / metal bumper |
|
|
Water tank volume |
20000L with water pump, front / rear sprayer, side discharger, water pipes and tail platform with water sprinkler. |
|
